Mercury 90 - Page 133

To Next Page

To Previous Page

2. Insert the steering cable into the tilt tube.

3725

3. Tighten the nut to the specified torque.

3727

Description

Nm lb‑in. lb‑ft

Nut 47.5 – 35

OUTBOARD INSTALLATION

eng 123
