FUEL HOSE CONNECTION
Remote Fuel Hose Size
Minimum fuel hose inside diameter (ID) is 8 mm (5/16 in.) with separate fuel
hose/fuel tank pickup for each engine.
Fuel Hose Connection
Fasten the remote fuel hose to the fitting with a hose clamp.
a - Hose clamp
b - Remote fuel hose
SHIFT CABLE INSTALLATION
NOTE: Install the shift cable to the engine first. The shift cable is the first cable
to move when the remote control handle is moved out of neutral.
Install the cables into the remote control following the instructions provided with
the remote control.
1. Position the remote control into neutral.
N
26838
2. Shift the outboard into neutral.
a
b
23709
OUTBOARD INSTALLATION
eng 141
