Mercury Big Tiller User Manual

Tiller Handle Component Location
a - Power trim switch
b - Throttle grip
c - Steering actuator adjustment collar (power steering models)
d - Throttle grip friction knob
e - Tiller handle lock knob
f - Tiller handle tilt friction adjustment jam nut
a - Ignition key switch
b - Lanyard stop switch
c - Lanyard
d - Gear shift handle
e - Troll speed control switch (if equipped)
b
a
c
e
33022
d
f
a
b
c
d
e
65276
TILLER HANDLE COMPONENTS
eng 1
