39
CB188
POWER TRIM OPERATION - PANEL MOUNT
REMOTE CONTROL
IMPORTANT: If TRAILER button is held depressed after drive
unit reaches end of upward travel, an internal circuit breaker will
open and pump will stop. Should this happen, release button
and allow motor to cool for about one minute. Circuit breaker
will reset and Power Trim operation may be resumed.
1 Trailer Position: Press button until drive unit reaches desired
height.
2 Trim Up/Out: Press UP on Trim switch until drive unit reaches de-
sired trim position.
3 Lower Drive Unit: Press DOWN on Trim switch until drive unit
reaches desired position.
CB189
POWER TRIM OPERATION - CONSOLE MOUNT
REMOTE CONTROL (SINGLE ENGINE VERSION)
4 Trailer Position: Press button until drive unit reaches desired
height.
5 Trim Up/Out: Press UP on Trim switch until drive unit reaches de-
sired trim position.
6 Lower Drive Unit: Press DOWN on Trim switch until drive unit
reaches desired position.
