43
CB193
POWER TRIM OPERATION - THREE BUTTON TRIM PANEL
(USED ON MODELS WITHTWO-LEVER CONTROL)
IMPORTANT: If TRAILER button is held depressed after drive
unit reaches end of upward travel, an internal circuit breaker will
open and pump will stop. Should this happen, release button(s)
and allow motor to cool for about one minute. Circuit breaker
will reset and Power Trim operation may be resumed.
1 Trailer Position: Simultaneously press the UP button (top) along
with the UP/OUT button (center) until drive unit reaches desired trail-
er position.
2 Trim Drive Unit UP/OUT: Press center UP/OUT button until drive
unit reaches desired trim position.
3 Trim Drive Unit IN/DOWN: Press IN button until drive unit reaches
desired trim position.
