MOUNT INSTALLATION
24 eng
5. Insert the rubber mounting isolators into the mounting holes.
Position the isolators in line with the mount base with the wider side
toward the outside of the mount base bracket.
6. Place the mount base on the isolators and align the holes. Install
the two longer screws into the front mounting holes and the two
shorter screws into the rear mounting holes. Tighten all of the
mounting screws securely.
IMPORTANT: The mount base must lay flush against the isolators
before being bolted to the deck or the mount will bind making it difficult
or impossible to unlatch.
7. The bracket should fasten securely and evenly with the latch pins
in the latch. The bracket should release with a light, quick snap of
the rope handle.
Gator Flex 360
Gator Flex 360
IMPORTANT: Choose an area on the deck which allows a 7.6 cm
(3 in.) clearance between the column and the bow of the boat for all
motor positions.
