CUSTOM APPLICATIONS
eng 43
IMPORTANT: Do not fully remove the top housing retaining bolt or the
retaining nut may fall out. Slowly raise the top housing off of the shaft
ensuring that the motor control wires do not disconnect. If the wires are
disconnected, refer to Motor Control Wiring.
a - Allen wrench
3. Remove the top housing from the column.
NOTE: On saltwater models, do not remove the heat sink grease on
the motor column. Heat sink grease will not wash out of clothing.
Top housing removed from column
4. Turn the top housing upside down to expose the direction control
switch inside.
5. Slide the switch away from the handle.
