OUTBOARD INSTALLATION
102
REMOTE BOAT HARNESS
Route the remote boat harness through the grommet. Connect the
remote harness to the 14 pin connector on the engine harness.
a - Remote 14 pin boat harness
BATTERY INFORMATION
!
WARNING
Failure to properly secure the battery leads could result in a loss
of power to the Digital Throttle and Shift (DTS) system, leading
to serious injury or death due to loss of boat control. Secure the
battery leads to the battery posts with hex nuts to avoid loose
connections.
• Do not use deep cycle batteries. Engines must use a marine
starting battery with 1000 MCA, 800 CCA or 180 Ah.
• When connecting engine battery, hex nuts must be used to
secure battery leads to battery posts. Torque nuts to
specification.
Description Nm lb. in. lb. ft.
Hex nuts 13.5 120
