20
Motherboard User’s Guide
3. Install the edge connector of the expansion card into the
slot. Ensure the edge connector is correctly seated in the
slot.
4. Secure the metal bracket of the card to the system
chassis with a screw.
CNR Slot
You can install the CNR (Communications and Networking Riser)
cards in this slot, including LAN, Modem, and Audio functions.
PCI Slots
You can install the 32-bit PCI interface expansion cards in the
slots.
