Mercury SC1000 User Manual

WARNING SYSTEM
8
NOTE: Not all screens may apply to your engine type.
MODE
RPM x 1000
0
2
3
4
5
6
7
1
RESET
TROLL
+
TROLL
-
FAULT
LOW FUEL
LOW OIL
FAULT
FAULT
FAULT
MAP
MAT
TPS
OIL PRESSURE
E F
E
F
22897
17
18
19
21
22
20
17.OIL PRESSURE: There is insufficient oil pressure.
18.LOW FUEL LEVEL The fuel level in the fuel tank is critically
low. Stop for fuel immediately to avoid running out.
19.LOW OIL LEVEL - OUTBOARD 2-STROKE ONLY: The oil
level in the remote oil tank is low. Stop and refill the oil tank
immediately to avoid running out.
20.FAULT - MAP: Engine problem occurred. Have the engine
checked by your dealer.
21.FAULT - MAT: Engine problem occurred. Have the engine
checked by your dealer.
22.FAULT - TPS: Engine problem occurred. Have the engine
checked by your dealer.
