TACHOMETER CALIBRATION
30
Tachometer CAL 2 Calibration
This calibration configures the system sensor inputs.
NOTE: The screens may vary depending upon the version of the
gauge.
1. Press and hold the "MODE/SELECT" and "+" buttons for
approximately ten seconds until the "CAL 2" screen appears.
2. Press the "-" or "+" button to select the option choice displayed
in the [ ] brackets on the screen.
3. Press "MODE/SELECT" ["SAVE"] to save the setting and
advance through the calibration screens.
FUEL TANK CALIBRATION
There are three methods for calibrating the fuel tank level
monitoring feature:
1. Do nothing. The linear readout is based on raw sensor values.
This mode does not factor in irregular tank shapes.
2. By performing the following tank calibration procedure, but
without actually adding fuel. The System Tachometer/Smart
Tow Tachometer will supply an estimated range value based
on linear interpolation of the sensor range values. This mode
does not factor in irregular tank shapes.
3. By performing the following tank calibration procedure
completely, which means adding fuel at each calibration point.
The System Tachometer/Smart Tow Tachometer will display
an estimated range value that factors in the tank shape.
CAL2 Tachometer Calibration - Tank 1 and 2 Level Calibration
Select "EDIT" to enter the calibration mode of
the fuel tank. The calibration procedure is the
same for tank 1 as it is for tank 2. Select "EDIT"
to begin tank level calibration.
