SYSTEM SPEEDOMETER DISPLAY SCREENS
11
System Speedometer Display Screens
NOTE: Not all screens may apply to your engine type.
When the ignition is turned on, the speedometer will show the last
screen that was displayed before the ignition was turned off.
Press "MODE" to change display screens. You can revert back to
the previous screen by pressing and holding "MODE" for 2
seconds.
NOTE: Readings can be displayed in English (U.S.) or Metric.
Refer to Speedometer Calibrations.
NOTE: Descriptions are not necessarily in order on the gauge.
Order changes depending on engine type.
1. Clock - Temp: Clock, air temperature and water temperature.
The air and water temperature sensors will have to be
connected to obtain display readings.
2. Fuel Level: Displays the amount of fuel remaining.
3. Oil Level: Displays the amount of engine oil remaining
(Outboard 2-Stroke only), or water/waste tank level (if
attached).
4. RPM Synchronizer: Dual Engines Only - Monitors the
revolutions of both engines.
5. Trim Synchronizer: Dual Engines Only - Displays the trim
position of both engines. Simplifies keeping trim levels equal.
