TACHOMETER CALIBRATION
31
CAL2 Tachometer Calibration - Tank 1 and 2 Level Calibration
EMPTY TANK
CALIBRATING :
THEN PRESS PLUS BUTTON
[SKIP]
[SAVE]
23995
Empty the tank. Select "SAVE" to calibrate the
tank level to empty.
FILL TO 1/4
CALIBRATING :
THEN PRESS PLUS BUTTON
[SKIP]
[SAVE]
24002
Fill the tank to 1/4 full. Select "SAVE" to calibrate
the tank level to 1/4 full.
FILL TO ½
CALIBRATING :
THEN PRESS PLUS BUTTON
[SKIP]
[SAVE]
24003
Fill the tank to 1/2 full. Select "SAVE" to calibrate
the tank level to 1/2 full.
FILL TO 3/4
CALIBRATING :
THEN PRESS PLUS BUTTON
[SKIP]
[SAVE]
24004
Fill the tank to 3/4 full. Select "SAVE" to calibrate
the tank level to 3/4 full.
FILL TO FULL
CALIBRATING :
THEN PRESS PLUS BUTTON
[SKIP]
[SAVE]
24005
Fill the tank to full. Select "SAVE" to calibrate
the tank level to full.
TANK 2 INPUT
OIL TANK
CALIBRATION 2
[SAVE][DOWN]
[ UP ]
24148
Select tank 2 input: oil tank, fuel tank 2, water
tank, waste tank, or not installed.
EXTERNAL SENSORS
CAL2 Tachometer Calibration - External Sensors
EXTERNAL SENSORS ?
CALIBRATION 2
[SKIP]
[EDIT]
24006
Selects and calibrates external sensors that are
installed in the system. Select [SKIP] to proceed
to the speed options. Select [EDIT] to proceed
to external sensor selection.
EXTERNAL SENSORS
CALIBRATION 2
PITOT SENSOR ? YES
[ NO ]
[SAVE] [YES ]
24007
Is the boat equipped with a pitot sensor to
measure boat speed? Press "-" to select no or
"+" to select yes.
EXTERNAL SENSORS
CALIBRATION 2
PADDLE SENSOR ? YES
[ NO ]
[SAVE] [YES ]
24008
Is the boat equipped with a paddle wheel to
measure boat speed? Press "-" to select no or
"+" to select yes.
