8M0127340 eng December 2017 © 2017 Mercury Marine
Application
What Engine Configurations are Supported?
The VesselView Module will work in any of the
following configurations:
• For single engine applications that do not have SmartCraft
architecture (an available junction box at
the helm), you can install the module directly
on the engine. This setup does require the
ten-pin termination resistor, typically yellow and
on the engine.
• For multi-engine applications that do not have SmartCraft
architecture (available junction box
under the helm), see your Mercury Marine dealer
for assistance with architecture configuration
and installation.
• For boats with SmartCraft architecture in place, use an open port
(remove weather cap) in a junction box or replace your junction box
with a higher capacity unit if all ports are already used.
