Mercusys MP500 User Manual

03
Chapter 1 Introduction
1.2.2 Physical Interface
Power Plug
The powerline adapter has a Plug that can be connected to a power socket.
Pair Button
Press and hold the button for 1 second to join a powerline network. Go to Secure
Powerline Network by Pairing for more information.
Press and hold for more than 6 seconds to reset the powerline adapter.
Ethernet Port
Connect the Ethernet port to your wired devices, such as a computer, a router or a
game console, via an Ethernet cable.
Power Plug
Gigabit
Ethernet Port
Pair/Reset
Button
LED Indicator
