Mercusys MU6H User Manual

02
Chapter 1 Introduction
Chapter 1 Introduction
1.1 Product Overview
MU6H receives Wi-Fi signals on two separate bands. Supporting 256-QAM technology
increases 2.4 GHz data rate from 150 Mbps to 200 Mbps for 33% faster performance.
Choose the 2.4 GHz for surng and social media, and 5 GHz for up to 433 Mbps for HD
streaming and lag-free gaming.
With a high gain antenna, the adapter reaches your router from farther with more
precise directional range, sustaining faster and more stable wireless connections.
1.2 Features
Ǵ Dual Band 2.4GHz and 5GHz Support
Ǵ 5 dBi High Gain Antenna
Ǵ Interoperate with other wireless (802.11b/g/n, 802.11a/n/ac) products
Ǵ Supports WPA/WPA2 data security, IEEE802.1x authentication, WEP encryption
Ǵ Provides USB 2.0 Interface
Ǵ Supports Infrastructure mode
Ǵ Easy to Install
Ǵ Supports Windows 10/8.1/8/7/XP (32/64 bit)
1.3 LED Status
You can check the adapter’s working status by following the LED Explanation table.
Status Indication
O
The driver is not installed.
The adapter is not detected.
Blinking
The driver has been installed successfully.
The adapter is working properly.

Mercusys MU6H Specifications

General

Antenna type	Omni-directional
Output power	- mW
Plug and Play	Yes
Product color	Black
Connector type	-
Frequency range	2400 - 5725 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Antenna gain level (max)	5 dBi
WLAN data transfer rates supported	200, 433 Mbit/s
Package depth	148 mm
Package width	207 mm
Package height	38 mm
Package weight	110 g

Weight and Dimensions

Depth	16.8 mm
Width	57.8 mm
Height	173.4 mm
