Chapter 3 - Connect to a Wireless Network
10
2. Log in to the Web Management page of your router or AP. Go to the WPS page, enter the PIN
of the adapter in the corresponding field and click Connect.
3. The following screen indicates successful connection by WPS. Click OK.
3.3 Windows Wireless Utility
Follow the instructions in the appropriate section below to use your computer system’s built-in
wireless utility: Windows 7/8/8.1/10, Windows XP
 Windows 7/8/8.1/10
1. Click the wireless icon
or
on the taskbar. Select the wireless network you want to
join and then click Connect. Enter your Wi-Fi password when prompted.
2. When Conne cted displays next to the network name (SSID) on the screen, it indicates a
successful network connection.

Mercusys MW150US Specifications

General

Internal	No
Product type	Portable router
Certification	CE, ROHS
Component for	-
Product color	White
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Frequency range	2.4 - 2.4835 GHz
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Not available
USB version	2.0
Connectivity technology	Wireless
Windows operating systems supported	Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Transmit power	0 dBmW
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Transmit power range	0 - 20 dBmW
Package type	Box
Package depth	100 mm
Package width	150 mm
Package height	28 mm
Package weight	56 g
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	14.8 mm
Width	18.9 mm
Height	6.85 mm
