Specification 49
DSP5000 User Guide
Specification
Digital inputs
32kHz, 44.1kHz or 48kHz. Double PLL locks at
44.1kHz ± 120ppm
Cable inputs: D1–2
IEC958, 75
Ω
Digital outputs
Copy of the selected input
Cable outputs: D Out
IEC958, 75
Ω
Communication
s
200-Comms Via Input and Output connections
RS232 Standard 9-pin: 2400b, 8, N, 1 no handshake
Power
Amplifiers
Complementary bipolar design, with output-
stage error correction and twin loop design
Tweeter 75W mean power
Mid + Bass 75W mean power
Bass 75W mean power
Digital to Analogue
conversion
18-bit Delta–Sigma converter running with 64-
times over sampling
Distortion <0.02%, typically less than 0.01% up to full
power at all frequencies
Noise and hum < –94dBr at all volume settings
Distortion <0.02%, typically less than 0.01% up to full
power at all frequencies
DSP processor Motorola DSP56001 running at 32MHz
Acoustic
Output Typically > 108dB spl @ 1m
Noise < 15dB spl @ 1m
Frequency response In room response within 3dB, 35Hz–20kHz
Crossover
Linear-phase ±30
° at 2.6kHz
Low frequency 6th-order quasi-Butterworth at 35Hz
Drive units
Bass 2 x 160mm polypropylene high-efficiency long-
throw custom drivers
Tweeter Meridian 25mm piston in short horn: aluminium
dome with silver voice-coil.
Cabinet
Constructed from fine veneered MDF
Dimensions 210 x 900 x 295mm
Weight 32 kg each
Power 100–125; 200-230; 210–250V AC 50–60Hz
20VA standby; 300VA max
