Meritor Differential Carrier 18X
2 Maintenance
While tilting the assembly engage the spigot bearing (Fig.2.43)
and install the R.H. cap assembly into locating holes (Fig.2.44).
4. Fit the cap screws and washers that hold the R.H- cap to the
carrier (Fig.2.45). Tighten all the cap screws by hand four to
six turns, then tighten to the correct torque value
200Nm+ 90°-105°.
5. Fit the L.H. split cap with a light plastic or rubber mallet
(Fig.2.44).
Fig. 2.43 Fig. 2.45
Fig. 2.44 Fig. 2.46
