Specifications and data
Hypoid pinion bearings
2 taper roller and 1 straight roller bearing
Differential unit
Final Drive Hypoid Gear Ratio (and bevel set teeth)* 2.47 (15/37): 2.64 (14/37): 2.85 (13/37): 3.08 (12/37):
3.36 (11/37): 3.67 (9/33): 3.40 (10/34): 4.11 (9/37):
4.63 (8/37): 5.29 (7/37): 6.17 (6/37)
Pinion to Drive Gear Backlash 0.21 ÷ 0.50 mm
Pinion to Crown Backlash Adjustment Adjusting Rings
Differential Bearing Cap Divergence 0.15 - 0.33 mm
Differential Bearing Cap Divergence Adjustment using the Ring Nut Adjusters
Thickness Range for the Shims fitted between the
Bevel Pinion Bearing Cage & the Differential Carrier 0.10 - 0.15 - 0.35 - 0.50 mm
Drive Gear runout 0.20 max mm
Pinion Bearing Preload 4 - 8 Nm without Pinion Seal
* Verify with the Engineering reference the range of the ratio in current production because sometimes some ratios could be already
released but not currently in production.
