Meritor 18X - Exploded View Parts List

9
Meritor Differential Carrier 18X
1 Introduction
Exploded view Parts list
1
2
3
4
5
6
7
8
9
10
11
12
Ref.
Description
Diff Carrier & Cap Assembly
1a Diff Carrier
1b Bearing Cap RH (Disjoint)
1c Bearing Split Cap LH
1d Capscrew - Bearing Cap RH
1e Capscrew - Bearing Cap LH
1f Bearing Cap Washer
1g Locator Pin
Differential Gear Set Assembly
2a Drive Pinion
2b Diff Assembly & Drive Gear - Welded
Diff Bearing LH Side
3a Diff Bearing Cup LH
3b Diff Bearing Cone LH
Diff Bearing RH Side
4a Diff Bearing Cup RH
4b Diff Bearing Cone RH
Adjusting Ring RH Side
Adjusting Ring LH Side
Lock - Adjusting Ring
Capscrew - M6 x 20
Outer Pinion Bearing
9a Outer Pinion Bearing Cup
9b Outer Pinion Bearing Cone
Inner Pinion Bearing
10a Inner Pinion Bearing Cup
10b Inner Pinion Bearing Cone
Spacer (Variable)
Shim - Inner Pinion Bearing Cup (0.10mm)
Shim - Inner Pinion Bearing Cup (0.15mm)
Shim - Inner Pinion Bearing Cup (0.35mm)
Shim - Inner Pinion Bearing Cup (0.50mm)
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Ref.
Description
Spigot Bearing
Pinion Seal
Companion Flange & Deflector Assy
15a - Companion Flange
15b - Deflector
Pinion Nut - M60
Shift Fork
Piston
“O”Ring (40mm diameter)
Shift Shaft Spring
Diff Lock Hole Cover
Gasket
Hex Head Capscrew - M6 x 20
Identification Plate
Clutch Shift Collar
Lock-Nut - Sensor Switch
Sensor Switch
Shift Shaft
Hole-End Plate Cover
Blanking Plug - Sensor Switch Hole
Washer Plug
