49
Meritor Differential Carrier 18X
4 Pinion Seal Replacement
9. Lock flange with service tool MST4400 - CT13 (Fig.4.14)
10. Tighten flange lock nut to a torque of 2000-2500Nm
(Fig. 4.15)
Fig. 4.14
Fig. 4.15
Fig. 4.17
Fig. 4.16
11. With a suitable ball nosed punch, indent lock nut in two
places directly above the slots in the flange.
(Figs. 4.16 and 4.17)
