15
1. Tiller - Similar in operation to the handlebars of a bicycle, this device is used
to steer the vehicle. It also contains the controls necessary to propel and
control the vehicle.
2. Tiller angle Adjustment Lever - When pull, allows the tiller angle to be set
for optimum driver comfort.
3. Arm-Rests - are width and angle adjustable. (see seating adjustments later
in this manual).
4. Anti-tip Wheels - Positioned one each side of the vehicle at the rear, these
wheels prevent a tip-over backwards.
5. Switch - This is used to turn vehicle power to ON and to OFF.
6. Wig-Wag Control Lever - This is used to control the speed and direction of
drive.
7. Removable Battery Pack - This pack holds one 24 volt battery.
