31
USER´S MANUAL
8. Technical specifications
Number of steps 6 or 12
Dimensions 155 x 155 x 70 mm
Frequency 48...52 Hz, 58...62 Hz
Measuring current 0...5 A
Measuring and supply voltages 88...130 V
185...265 V
320...460 V
Relay outputs 120 Vac/5A, 250 Vac/2A, 400 Vac/1A
110 Vdc/0,3A, 60 Vdc/0,6A, 24 Vdc/2A
Display LCD glass with 160 symbols, backlighted
Protection class IP41 front panel, IP20 rear part
Target cos
-range 0,85 ind...1,00...0,90 cap
Response limits, C/K 0,01...1,99 symmetrical
Reconnection delay 10...600 s
Response delay 20 % of reconnection delay, min. 10 s
Displayed measurements cos
, P, Q, S, THD(U), temperature
Installation method Panel installation, DIN-rail installation
Casing Impact resistant PC/ABS, UL94V-0
Operating temperature range 0...60°C
Alarm log List of 5 last alarms
Step counters Yes
Fan control with dedicated relay Yes
Accuracy (of FS) Is: 5%
Iq: 5%
U/I-samples: 5%
Phase: 5°
Distortion: ±3 dB (up to 11
th
)
Temperature: ±3°C
CT setting range 25/5...6000/5
Power outage detection Reaction time > 15 ms
Approvals IEC 61010-1
IEC 61000-6-2
IEC 61000-6-4
IEC 61326
