Merlin MT3850EVO - Replacement Parts

28
REPLACEMENT PARTS - Information for Service Personnel
NO
T
I
CE
041A2828
Release rope
a
nd handle
012B0905
Door bracket
178B0034B
Straight arm
012C0778
Rail chassis straps
083A0011
G
rease
0
41A5414-9
H
ardware bag
012B0906
Door bracket plate
041A5800
Outer trolley
1
83D0177
Segmented rail sections
1
83D0178
Segmented rail braces
012C0855
Header bracket
1
71A0028
031D0537
Belt pulley cover
Replacement belt packs
041A5844 (2.3m)
041A5844-1 (2.5m)
041A5844-2 (3.0m)
8423CR3
8430CR3
One Piece Rails
8023CR3 2.3m
8025CR3 2.5m
8030CR3 3m
041B4103
Belt tensioner
0
41A6398
Inner trolley repair kit
1
4
4
C
0
0
7
7
I
d
le
r
p
u
ll
e
y
012C0810
E
nd bracket 30mm steel
178B0086B
Curved arm
041B5669
Belt joining Kit
Required for shortening belts
