Merlin MT3850EVO - Planning

Safety
Reversing Sensor
S
upport bracket &
fastening hardware
i
s required.
R
efer page 12.
— — — — — — — —
Header Wall
F
INISHED CEILING
T
orsion
Spring
Safety
Reversing Sensor
Gap between floor and bottom
of door must not exceed 6 mm
Access
Door
Wall-
mounted
Door
Control
Opener
V
ertical
Centreline
of Door
3
SECTIONAL DOOR INSTALLATION
Planning
I
dentify the type and height of your garage door. Survey your garage area to see if any of the conditions below apply to
your installation. Additional materials may be required. You may find it helpful to refer back to this page and the
accompanying illustration as you proceed with the installation of your opener.
