Merlin MT60 - Completed Installation Example

1
2
3
12
4
5
9
7
10
11
13
14
6
8
15
10
(1) Header Sleeve
(2) Idler Pulley Bracket
(3) Trolley
(4) Rail
(5) Chain
(6) Hanging Bracket
(7) Power Cord
(8) Opener
(9) Light Lens
(10) Manual Release Rope & Handle
(11) Curved Door Arm
(12) Straight Door Arm
(13) Door Bracket & Plate
(14) Header Bracket
(15) Trolley Release Arm
4
As you proceed with the assembly, installation and adjustment procedures in this manual, you may find it helpful to
refer back to this illustration of a completed installation.
4
COMPLETED INSTALLATION (TILT DOOR EXAMPLE SHOWN)
