Lighting Control Switch Version: A0
Page 2 of 11
eatures1.
Features
2.Parameter
Input
Operating Voltage Rage 108-305V AC, 50Hz/60Hz
DC Input Voltage N/A
Rated Voltage 120/277Vac,60Hz
No-load Power N/A
Stand-by Power <1W
Surge Test L--N: 1kV
Output
Working Mode
ON/OFF function, 1-10V step dimming
Type of Load Inductive or resistive Load
Load Capacity 120VAC: 4A; 277VAC: 3A
Current of Load N/A
Max. Surge Capacity
50A (50% Ipeak, twidth =500uS, 230Vac full load, cold start);
80A (50% Ipeak
,
twidth =200uS, 230Vac, full load, cold start)
Dim Interface
1-10V Dimming
< 50mA （Non-constant source）
10%(1.4-1.6V), 20%(1.9-2.1V),
30%(2.9-3.1V), 50% (4.9-5.1V)
Synchronous Control N/A
High Low-level N/A
PWM Control N/A
Sensor
Parameters
Operating Frequency 5.8 GHz ±75 MHz, ISM Band.
Transmitting power 0.5mW Max.
Operating voltage 120~277V AC, suitable to
Euro & North American market.
Patented microwave antenna, mounting height is
15m Max, suitable to install in most of
warehouses.
Supports high-sensitivity and low-sensitivity
modes (for metal ceilings, metal reflector
mounting environments)
Work with 1-10V dimmable LED driver, easy to
achieve 2-step or 3-step dimming function.
New patented remote control to adjust the
transmitting angle to avoid misuse.
5 years warranty
