Lighting Control Switch Version: A0
Page 3 of 11
Hold time 5s/30s/1min/3min/5min/10min/20min/30min
Stand-by DIM Level 10%/20%/30%/50%
Stand-by Period 0s/10s/1min/3min/5min/10min/30min/+∞
Detection Area 25%/50%/75%/100%
5lux/15lux/30lux/50lux/100lux/150lux/Disable (Ambient light
diffusion)
Detecting Radius See note 2
Mounting Height 15m Max
Detecting Angle 150°(wall mounting), 360°(ceiling mounting)
Wireless
Module
Operating Frequency N/A
Transmitting power N/A
Transmitting distance N/A
Modulation mode N/A
Number of coding N/A
Operating
Environment
Operating Temperature -35 …+55℃℃
Storage Temperature
Temperature:-40℃…+80℃;Humidity:10%-95%
(non-condensing)
Certificate
Standards
Safety standards
IEC60669-2-1, IEC60669-1
AS/NZS 60669.1, AS/NZS 60669.2.1
UL60730-1
EMC standards
EN55015, EN61000-3-2, EN61000-3-3, EN61547
AS/NZS CISPR 15, AS/NZS 4268
FCC Part 15C, Part 15B
EN 60950-1, EN301489-1, EN 201489-3, EN300440
Environmental Requirem
ent
Compliant to RoHS
Certificate cULus, CE, SAA, FCC, RED
Others
Wiring
SJTW,5*18AWG (USA); H05RR-F,5*18AWG (Europe,Australi
a)； exposed line length: 810-830mm
Wiring color
Sheath: Black Core: Red,White,Black,Gray,Purple (US);
blue, brown, red, purple,Gray (Europe, Australia)
IP Rating IP65
Protection Class Class II
Installation Independent
Dimension (ΦxH)72*59mm
Package
Instruction+ White box+ White box tags+ Clapboard+
Carton(K=A)
Net Weight
MC054V RC A: 225g, MC054V RC B:246g,
MC054V RC C:225g , MC054V RC D:165g
Lifetime 5 years warranty @Ta 230V full load
