Installing AP1000
© 2010 Meru Networks, Inc. Installing AP1000 65
AP1000 Beta Test
Figure 41: AP1000 Locked to a Wall
Set AP1000 on a Shelf
Set AP100 on any horizontal surface and then connect a PoE Ethernet cable.
Figure 42: AP1000 Ethernet Port on the Right
Mount AP1000 Above a Suspended Ceiling (Plenum)
AP1000 is not plenum rated and may only be mounted above the ceiling in a space that is not plenum,
such as a return airflow for air conditioning.
Caution!
Be sure to connect the Ethernet cable to the Ethernet port. The cable can
mistakenly be plugged into the Console port; if you do this. the AP won’t power up.
00248
12
