Mesa/Boogie MARK 5 THIRTY-FIVE User Manual

where the 35 WATT setting would still be clean and have ample headroom. 25 WATTS offers that perfect window… easy to push into
clip and loud, but not too loud… powerful enough to play with a drummer, but not so powerful that you’re melting eardrums in the front
row. And finally, we HAD to include this Mode… the success of the MARK FIVE: 25 was so strong, we dared not risk leaving that
magic combination, one of the most usable wattage ranges of all, out of its bigger brother’s trick bag.
The 10 W position (toggle down) rewires the EL84 output tubes to Class AB Triode style wiring for a more vintage-voiced and oh-so-
clip-able low power character. This produces less output, a smoother voice that clips with softer attack characteristics and a creamier
feel. 10 WATTS will be the choice any time you need the sound either very quiet, or very infused with power clip. The harmonic
content is different as well, with the upper harmonics being chime-y, but also very balanced and blended. With the top Channel’s
CLEAN and FAT Modes, there are a world of great Blues and Roots sounds to be found using the preamp’s GAIN set pretty high in
combination with the MID set up into its “BOOST” region (12:00 5:30). Here you’ll retain most of the CLEAN Mode’s dynamic content
and articulate, open attack characteristic, but be able to weave in and out of a soft clip–or much more–at will with either your guitar’s
Volume Control or even just your picking dynamics.
This exclusive MESA Dyna-Watt power circuit has been appreciated by players around the world for decades and has furthered the
reputation that Boogie’s were the “little amp that could” since its introduction in the now-classic Studio 22 Combo back in 1984. Now
combined with the incredible versatility of the MARK FIVE: 35’s two Channel preamp and 6 distinctive Modes, that reputation is safe
and secure for future generations to enjoy.
POWER
This toggle switch delivers the A.C. power to the MARK FIVE: 35. Make sure the amplifier is grounded (all three terminals
of the A.C. power cord connected) to avoid injury to the user as well as to the amplifier. Also make sure the proper voltage (117–125
Volts AC Domestic US Model) is present at the wall socket.
Always follow the Cold Start Procedure described in the STANDBY section when powering up your amplifier. This will
reduce the likelihood of tube problems and increase their musical life.
STANDBY
Perfect for set breaks...this toggle switch also serves an even more important purpose. From Cold-Start, the STANDBY
position allows you to warm up the tubes—especially power tubes— before applying the high voltage to them by switching the Standby
to the “ON” position. Before POWER is switched to “ON” - make sure the STANDBY switch is set in the “STANDBY” position.
Cold-Start Procedure:
Flip the POWER SWITCH to ON, then wait at least 30 seconds for the tube filaments to warm up and then flip the STANDBY switch to
the ON position. This prevents the shock of high voltage hitting cold tubes and reduces the likelihood of tube problems and increases
their toneful life substantially.
NOTE: This Cold Start Procedure is an important part of ensuring maximum tube life and reliability. Like a light bulb, the most wear
occurs in the instant (short period, first few seconds) voltage is first applied. Like a light bulb, if a dimmer is used to reduce the volt-
age for the first few seconds or so of use, increased longevity is the result. The STANDBY is the amp’s equivalent to a dimmer and
using it in the above described method will ensure the longest life and best performance from a set of tubes (especially Output tubes).
That covers the Inputs, Channels, Modes and Controls found on the Front Panel of the MARK FIVE: 35, now let’s swing around to the
Rear Panel and take a look at the Outputs, Features and Controls located there.
PAGE 25
CLEAN
CRUNCH
FS
MK IIC+
MK
IV
XTREME
GAIN TREBLE
MID BOOST
MID PRESENCE MASTER
SOLO 1
SOLO 2
BASS
FAT
EQ ON
EQ PWR
O
O
EQ FS
SPKR
ON
CLOSED
BACK
VINTAGE
CabClone™
D.I.
SPKR
OFF
EQ ON
EQ FS
CAUTION: Unplug
power before
servicing
120 V~
60 Hz
2 A
2 A
SLO
BLO
AMPLIFIER
44YV
HEADPHONERETURNSEND 4 OHM 8 OHM4 OHM
REVERB
CH 2 CH 1
MARK FIVE: 35™
VACUUM TUBE
AMPLIFIER
MADE IN PETALUMA, CA
WITH THE WORLD’S
FINEST MATERIALS
80Hz 240 750 2200 6600
35 W
25
10 W
35 W
10 W
FX
SPEAKERS
LIFT
GROUND
OPEN
FOOT SW.
TUBE GUIDE
6 x 12AX7
4 x EL 84
PATENTED
6,621,907
6,724,897
7,602,927
25
POWER
ON
ON
STANDBY
MARK
5
THIRTY-FIVE
™
INPUT
