Mesa/Boogie WalkAbout

REAR PANEL CONTROLS:
FUSE:
This is the A.C. Mains Fuse for the WalkAbout REPLACE ONLY WITH A SLO-BLO TYPE FUSE OF THE PROPER
RATING. THIS IS EXTREMELY IMPORTANT, AS THE
WalkAbout DRAWS A SUBSTANTIAL AMOUNT OF CURRENT AT HIGH
OUTPUT LEVEL SETTINGS.
AC RECEPTACLE:
The removable “Euro” Style” A.C. cord that is supplied with the WalkAbout makes set-ups and tear-
downs after the gig a snap. It also makes de-racking much easier when you wish to remove the unit from a hard wired rack system
where all the A.C. cords have been cable-tied in. Additional heavy duty cords are available should you ever need
one...simply call us direct and we can ship one directly to you for a nominal charge, plus shipping cost. Make sure
the A.C. cord is firmly in its socket (receptacle) before powering up the amplifier.
NOTE: NEVER ALTER THE THREE PRONG POWER CORD IN ANY WAY.
NOTE: NEVER BLOCK OR ALTER AIR ANY OF THE VENTED AREAS ON THE REAR PANEL OF THE AMPLIFIER.
CAUTION : Unplug power
