7I76 34
REFERENCE INFORMATION
SSLBP
7I76 SPECIFIC PROCESS DATA EXAMPLE
In the default input/output mode the process data appears in the interface registers
in the order shown:
7I76 OUTGOING PROCESS DATA FOR MODE (1)
CS REG
X X X X
INTERFACE 0
SPINOUT 15..8 SPINOUT 7..0 TB5 OUTS 15..8 TB6 OUTS 7..0
INTERFACE 1
X X SPINDIR SPINENA
INTERFACE 2
X X X X
7I76 INCOMING PROCESS DATA FOR MODE (1)
CS REG
REMOTE. FLT COM_STATE STATUS LOCAL FLT.
INTERFACE 0
TB5 INS 31..24 TB5 INS 23..16 TB6 INS 15..8 TB6 INS 7..0
INTERFACE 1
ANALOG3 ANALOG2 ANALOG1 ANALOG0
INTERFACE 2
X X X X
Note that this information is just for user convenience as the process data
organization in the interface registers can be determined by process data discovery.
