Mesa 7I76 - Example Rpc Command List

7I76 47
REFERENCE INFORMATION
LBP
EXAMPLE RPC COMMAND LIST
This is an example stored RPC command list. Note RPC command lists must start
at a RPCPitch boundary in the RPC table but an individual RPC list can extend until the
end of the table. This particular RPC example contains 2 LBP commands and uses 7 bytes
starting at 0x0028 (RPC5 for 0x08 pitch RPC table)
Command1. Writes two data bytes to address 0x10, 0x11 with 2 data bytes supplied by
host
Command2. Reads two data bytes from address 0x12,0x13
COMMAND BITS CT1 CT0 WR RID I AS DS1 DS0
LBPWrite: 2 add 2 data
0 1 1 0 0 1 0 1
Write Address LSB 0 0 0 1 0 0 0 0
Write Address MSB 0 0 0 0 0 0 0 0
LBPRead: 2 add 2 data
0 1 0 0 0 1 0 1
Read Address LSB 0 0 0 1 0 0 1 0
Read Address MSB 0 0 0 0 0 0 0 0
Terminator
0 0 0 0 0 0 0 0
The data stream for this RPC would consist of these 3 bytes:
COMMAND BITS CT1 CT0 R5 R4 R3 R2 R1 R0
RPC 5
1 0 0 0 0 1 0 1
Data 0 for Command 1 0 1 0 1 0 1 0 1
Data 1 for Command 1 1 1 0 0 1 1 0 0
