REFERENCE INFORMATION
SSLBP
PROCESS DATA ELEMENT PACKING AND UNPACKING
After the DOIT command has completed, the incoming process data (IPD in table
below) can be read along with the local and remote faults.
HOST READS INCOMING INTERFACE REGISTERS AFTER DOIT
CS REG
REMOTE. FLT COM_STATE STATUS LOCAL FLT.
INTERFACE 0
IPD BYTE 3 IPD BYTE 2 IPD BYTE 1 IPD BYTE 0
INTERFACE 1
IPD BYTE 7 IPD BYTE 6 IPD BYTE 5 IPD BYTE 4
INTERFACE 2
IPD BYTE 11 IPD BYTE 10 IPD BYTE 9 IPD BYTE 8
7I76 SPECIFIC PROCESS DATA EXAMPLE
Process data is remote device dependent and also dependent on remote device
mode. The 7I76 supports 3 software modes.
