DEFCOM 3.1B Installation Manual
3. GENERAL WIRING DIAGRAM
ANTENNA
(do not cut and do not tape
together with rest of cable
harness)
NEGATIVE
SUPPLY (-)
LED
HORN RELAY
NEGATIVE
COMMAND
IMMOBILISER
POSITIVE
SUPPLY
(+12V)
DIRECTION
INDICATORS
Mount
15A Fuse
RED
LIGHT BLUE
ORANGE
YELLOW/GREEN
VIOLET
DARK BLUE (C)
GREY (NO)
BROWN
WHITE
BLACK
LIGHT BLUE
IGNITION SWITCH
POSITIVE SUPPLY
(+15)
PROTECTION AGAINST
REMOVAL OF EARTH
CONNECTION (CONNECT
TO EARTH IF NOT USED)
PROTECTION FOR
EARTH CONTACT
RED
BLACK
Fig.3
PAIRING THE RADIO
REMOTE CONTROLS
11
