17
ENGLISH
1. Machine overview (standard delivery)
2
3
4
6
7
10 11 12
9
8
14
15
17
16
13
18
19
1
5
General operating elements
1 Swing table
2 Ratchet lock lever for sawhead
tilt
3 Side panels
4 ON/OFF switch
5 Folding
workstand
Tools
6 Allen key 8 mm
7 Allen key 6 mm
Machine documents
Operating instructions
Spare parts list
Table saw mode
8 Handwheel for depth of cut set-
ting
9 Riving knife
10 Blade guard
11 Push stick
12 Rip fence
Crosscut and mitre saw mode
13 Release lever
14 Saw handle
15 Rotating table
16 Fence
17 Chip case for saw blade
18 Locking pin, rotating table
19 Retractable blade guard
XA0029E5.fm Operating Instruction ENGLISH
