Metabo SBE 780-2 User Manual

ENGLISHen
12
opening. The application of cleaning spray to the
jaws and jaw openings at regular intervals is recom-
mended.
Electronic signal display (10):
Rapid flashing - restart protection
(SBEV 1300-2, SBEV 1300-2 S, SBEV 1100-2 S,
SBE 1000-2)
When power is restored after a power failure, the
machine - which is still switched on - will not start for
safety reasons. Switch machine on and off again.
Slow flashing - carbon brushes worn
(SBEV 1300-2, SBEV 1300-2 S, SBEV 1100-2 S)
The carbon brushes are almost completely worn. If
the brushes are completely worn, the machine
switches off automatically. Have the brushes
replaced by an authorized service centre.
Permanently lit - overload
(SBEV 1300-2, SBEV 1300-2 S, SBEV 1100-2 S)
If the machine is subject to long periods of contin-
uous overloading, the power input of the machine is
limited. This prevents the further unauthorized
heating of the motor.
Run the machine in idling until it cools down and the
electronic signal display switches off.
Use only genuine Metabo accessories.
Use only accessories which fulfil the requirements
and specifications listed in these operating instruc-
tions.
Fit accessories securely. Secure the machine if it is
operated in a bracket. Loss of control can cause
personal injury.
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out by
qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Fig. O. We reserve the right to make technical
improvements.
P
1
=Rated input
P
2
=Power output
I
120 V
=Current at 120 V
n
1
* = No-load speed
n
2
* = Load speed
max. dia. =Max. solid drill diameter
s max =Max. impact rate
b =Chuck capacity
G =Spindle thread
H =Spindle with hexagon socket
m =Weight
D =Collar diameter
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
* Energy-rich, high-frequency interference can cause
fluctuations in speed. The fluctuations disappear,
however, as soon as the interference fades away.
Emission values
Using these values, you can estimate the emis-
sions from this power tool and compare these with
the values emitted by other power tools. The actual
values may be higher or lower, depending on the
particular application and the condition of the tool or
power tool. In estimating the values, you should also
include work breaks and periods of low use. Based
on the estimated emission values, specify protective
measures for the user - for example, any organisa-
tional steps that must be put in place.
Vibration total value (vector sum of three directions)
determined in accordance with EN 60745:
a
h, ID
=Vibration emission value (impact drilling
into concrete)
a
h, D
=Vibration emission value
(drilling into metal)
K
h,ID
,K
h,D
=Uncertainty (vibration)
Typical A-effective perceived sound levels:
L
pA
=Sound pressure level
L
WA
=Acoustic power level
K
pA
, K
WA
= Uncertainty
Wear ear protectors!
10. Troubleshooting
11. Accessories
12. Repairs
13. Environmental Protection
14. Technical Specifications

Metabo SBE 780-2 Specifications

General

Chuck type	Keyless
Hammer drilling	Yes
Input power	780 W
Output power	470 W
Power source	AC
Torque (max)	32 N⋅m
Number of gears	2
Idle speed (max)	3100 RPM
Sound pressure level	103 dB
Sound level uncertainty	3 dB
Impact rate (high speed)	58900 bpm
Drilling diameter in wood (max)	40 mm
Drilling diameter in steel (max)	13 mm
Vibration level (metal drilling)	4.2 m/s²
Drilling diameter in concrete (max)	18 mm
Uncertainty K	1.5 m/s²

Weight and Dimensions

Weight	2600 g
