Metabo TKHS 315 M - 1 Scope of Delivery

ENGLISH
22
1. Scope of delivery
1
2
4
5
6
10
11
12
13
14
15161718
19
7
8
3
9
21
22
23
20
1 Plate, table rear extension
2 Blade guard
3 Suction hose
4 Fence carrier, lower
5 Fence extrusion, short
6 Fence carrier, upper
7 Rip fence
8 Hose carrier
9 Table panel, c/w with motor carrier
unit, motor, switch, saw blade, riv-
ing knife, dust extraction port
10 Accessory storage (2x)
11 Transport handle (2x)
12 Leg (4x)
13 Stanchion, short (2x)
14 Stanchion, long (2x)
15 Spanner for saw blade change
16 Spanner for saw blade change
17 Handle for push block
18 Push stick / feeding aid
19 Wheel set
20 Guide bar for mitre fence
21 Support (2x)
22 Mounting bracket (2x)
23 Bracket, for rear extension table
(2x)
– Operating instructions and spare
parts list
– Hardware bag
I_0014en4A.fm 5.2.16 Original operating instructions
