TEROS 10
PHYSICAL SPECIFICATIONS
Dimensions
Length 5.1 cm (2.02 in)
Width 2.4 cm (0.95 in)
Height 7.5 cm (2.95 in)
Needle Length
5.4 cm (2.11 in)
Cable Length
5 m (standard)
40 m (maximum custom cable length)
NOTE: Contact Customer Support if a nonstandard cable length is needed.
Connector Types
3.5-mm stereo plug connector or stripped and tinnedwires
ELECTRICAL AND TIMING CHARACTERISTICS
Minimum 3.0 VDC
Typical NA
Maximum 15.0 VDC
Operating Temperature Range
Minimum –40 °C
Typical NA
Maximum 60 °C
NOTE: Sensors may be used at higher temperatures under certain conditions; contact Customer Support
for assistance.
Measurement Duration
Minimum 25 ms
Typical NA
Maximum 50 ms
