OPERATION & SETTING Maintenance
To control the temperature of the shower, turn the left handle for more hot To replace the flow control valve:
or cold water, in the direction indicated by the marking. Turn off water supply
Remove handle by forcing off handle cap
To control the flow of water turn the handle to regulate the flow of water from the Inside the handle, remove the screw
shower in the direction shown on the mixer. Pull handle from valve.
Take note of stop ring positioning for re-fit
The product also has override buttons, the flow control allows for Pull off stop ring.
reduced flow, to activate full flow, press the button and continue Remove valve from mixer, using a spanner unscrew the nut
to turn the handle then unscrew the valve, taking care not to damage the pipe work
The temperature control allows for a temperature stop position Clean or replace valve as necessary.
this can be exceeded by pressing the button and continuing to Replace all components, turn on water supply and check for leaks.
turn the handle
If on installation the temperature is not to your requirement, this can be re-calibrated.
Turn temperature handle to fully hot.
Remove the handle cap , followed by the screw
Pull handle from valve.
Turn the spindle on the thermostat until the desired temperature is reached.
(Always maintain the 10c difference between supply and mixed)
Once the temperature is reached, replace the handle so that the stop is in the maximum
position, replace screw and handle cap.
Re-calibration should only be carried out when absolutely necessary
