2. Installation and Set-Up
CAUTION! Follow approved procedures and take all necessary preventive safety measures
when lifting and installing this equipment. Improper lifting can result equipment damage.
FORCIMAT is an optional accessory of FORCIPOL series of Grinding & Polishing Machine.
FORCIMAT is mounted on FORCIPOL. Please be sure that the platform is large enough and can
stand it’s weight.
In order to work with equipment comfortably, it is recommended to leave at least 30 cm space
from all side of the equipment.
You can see the dimensions and weight of FORCIMAT and FORCIPOL as below:
Place the FORCIMAT on FORCIPOL with convenient access to a 1-phase grounded power source, water
supply and water drain. Make the connections of the air hose and the data cable between FORCIMAT
Head and the FORCIPOL.
