95-1005
KIT ASSEMBLY
6
You will need to cut and remove the tabs according to the chart and refer-
ring to the diagram below:
The 2002-2005 Kia Sedona and the 2001-2003 Kia Spectra will use the tabs
marked by the number 2 on the brackets. Note: For the 2001-2003 Kia
Spectra proceed to page 9 for Final Assembly.
The 2002-2005 Kia Rio will use the tabs marked by the number 3 on the
brackets.
The 2003-2006 Sorrento LX and the 2004-2006 Kia Spectra will use the tabs
marked by the number 1 on the brackets.
1
2
3
1
2
3
L
R
TAB REMOVAL INSTRUCTIONS
To Next Page
