Chevrolet Corvette
2005-2009
1. Unclip and remove ride control
switch/blank plate at front edge of
center console lid, Step 2.
2. Remove (2) 9/32” screws from under
the removed blank plate, Step 3.
3. Unclip and remove entire panel
surrounding radio and including A/C
controls, Step 4.
4. Remove (4) 9/32” screws securing radio
to extract from sub dash, Step 5.
Continue to kit assembly
Dash Disassembly 95-3304
5
To Next Page
