Metra Electronics 95-3305 - Suzuki XL-7 Dash Disassembly

95-3305 or 99-3305
®
5
1. Press in on sides of the shifter boot to release it
from the shifter trim panel. (Figure A)
2. Lift the boot up to access the Allen screw securing
the shifter knob to the shifter lever. Loosen the
Allen screw and remove the shifter knob. (Figure B)
3. Remove (1) Torx screw from the shifter trim panel.
(Figure C), then using the panel removal tool
unsnap the shifter trim panel. Unplug and remove the panel. (Figure D)
4. Using a panel removal tool unsnap the radio trim panel. Unplug and
remove the panel. (Figure E)
5. Remove (4) 7mm screws securing the radio. Unplug and remove the
radio.
Continue to kit assembly
Suzuki XL-7 2007-2009
(Figure A)
(Figure B)
12:02
103:5
(Figure C)
(Figure E)
Dash Disassembly
AUX
B
A
N
D
FWD
RE
V
SEEK
SEEK
PA
SSENGER AIR BAG
AUX
(Figure D)
