Metra Electronics 95-3305 - Kit Assembly; ISO DDIN Radio Provision Assembly

®
95-3305
9
Kit Assembly
(Figure B)
ISO DDIN radio provision
1. Slide the ISO DDIN radio brackets
into the radio housing, aligning the
holes in the radio housing to the clips
on the brackets. (Figure A)
2. Slide the radio into the completed
assembly, and then secure using
the screws supplied with the radio.
(Figure B)
3. Locate the factory wiring harness
and antenna connector in the
dash and complete all necessary
connections to the radio. Metra
recommends using the proper
mating adapter from Metra or
AXXESS. Test the radio for proper
operation.
4. Reassemble the dash in reverse
order of disassembly.
Suzuki XL-7 only: Trim the top corners
of the radio housing. (Figure C)
(Figure A)
(Figure C)
