95-3305 or 99-3305
®
1. Unclip the radio trim panel
including the climate controls.
2. Unplug the climate controls and
remove the panel.
3. Remove (4) 7mm screws securing
the radio. Unplug and remove the
radio.
Continue to kit assembly
Buick Enclave 2008-2012/Chevy Traverse 2009-2012/
GMC Acadia 2007-2012/Saturn Outlook 2007-2010
Buick Enclave/Chevy Traverse Saturn OutlookGMC Acadia
7
Dash Disassembly
