95-3527 DASH DISASSEMBLY
PONTIAC GRAND PRIX 2004-07
A
B
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Remove trim ring around key cylinder.
(Figure A)
2
Unclip and remove entire panel sur-
rounding radio including message
center and vents.
(Figure B)
3
To remove radio start at bottom of
stack and remove (8) 9/32” screws
from pocket, climate control, and
radio (4) on each side).
(Figure C)
4
Continue to kit assembly.
C
