3
95-3527 KIT ASSEMBLY
B
A
STACKED ISO UNITS PROVISION
Slide the stacked ISO units into the
Double DIN bracket/radio housing
assembly and secure the units to the
kit using the screws supplied with the
units.
(Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure A)
1
Snap the Double DIN trim-plate onto
the front of the housing/radio assem-
bly.
(Figure B)
3
