Metra Electronics 95-7318 - Dash Disassembly; Disconnect Battery Terminal; Remove Dash Panel Assembly; Extract Radio Mounting Screws

95-7318
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove entire panel sur-
rounding radio and including A/C
controls.
(Figure A)
2
2005-2006 KIA SPECTRA 5
Remove (4) Phillips screws to extract
radio from dash.
(Figure B)
3
DASH DISASSEMBLY
A
B
